摘 要
本文設計了一臺簡易剪板機，能夠實現對厚度10mm，寬度700mm行剪切，剪斷時間小于10s，重點就機架、刀架等重要部件進行了設計，在設計中通過對比國內外剪板機，力求設計出結構簡單，操作簡便，同時經濟、合理的剪板機，具體設計思路上：減少了剪切的時間并且提高了剪切精度。采用人工送料以降低成本。近年來，隨著模具技術和沖壓技術的發展，剪板機的應用范圍在不斷地擴大，數量在不斷地增加。預計不久的將來，剪板機在沖壓用剪板機中的比例將會愈來愈大。
關鍵詞 機架; 刀架; 剪切精度
Abstract
This text designed to the infrastructure design of guillotine shear, can carry out to shear to slice the plank material thickness 10 mm, the width 700mm, clipping time is smaller than 10 second, the point carried on a design for the parts with important etc. of the machine, knife and passed contrast to the infrastructure design of guillotine shear at home and abroad in the design and tried hard for to design structure simple, operate simple, economic in the meantime, reasonable of the infrastructure design of guillotine shear, for the put type knife formely and connect the pole type knife carried on innovation: consumedly reduced to shear to slice of time and raised to shear to slice accuracy.In recent years, along with molding tool technique and hurtle to press a technical development, the infrastructure design of guillotine shear at constantly extension, amount at constantly increment.Anticipate near future, the infrastructure design of guillotine shear at blunt press to use to shear the comparison in the infrastructure design of guillotine shearr will be bigger and bigger.
Keywords Machine；Knife；hear to slice accuracy.
...
