制動器畢業設計全套
摘 要
國內汽車市場迅速發展，而轎車是汽車發展的方向。然而隨著汽車保有量的增加，帶來的安全問題也越來越引起人們的注意，而制動系統則是汽車主動安全的重要系統之一。因此，如何開發出高性能的制動系統，為安全行駛提供保障是我們要解決的主要問題。另外，隨著汽車市場競爭的加劇，如何縮短產品開發周期、提高設計效率，降低成本等，提高產品的市場競爭力，已經成為企業成功的關鍵。
本說明書主要介紹了santana2000轎車制動系統的設計。首先介紹了汽車制動系統的發展、結構、分類，并通過對鼓式制動器和盤式制動器的結構及優缺點進行分析。最終確定方案采用液壓雙回路前盤后鼓式制動器。除此之外，它還介紹了前后制動器、制動主缸的設計計算，主要部件的參數選擇及制動管路布置形式等的設計過程。
關鍵字：制動；鼓式制動器；盤式制動器；液壓
Abstract
The rapid development of the domestic vehicle market, saloon car is an important tendency of vehicle. However, with increasing of vehicle, security issues are arising from increasingly attracting attention, the braking system is one of important system of active safety. Therefore, how to design a high-performance braking system, to provide protection for safe driving is the main problem we must solve. In addition, with increasing competition of vehicle market, how to shorten the product development cycle, to improve design efficiency and to lower costs, to improve the market competitiveness of products, and has become a key to success of enterprises.
This paper mainly introduces the design of braking system of the santana2000 type of car. Fist of all, braking system’s development, structure and category are shown, and according to the structures, virtues and weakness of drum brake and disc brake, analysis is done. At last, the plan adopting hydroid two-backway brake with front disc and rear drum. Besides, this paper also introduces the designing process of front brake and rear brake, braking cylinder, parameter’s choice of main components braking and channel settings.
Key words: braking; brake drum; brake disc; hydroid pressure
